LED Innovation for Every Vision
Ultra-Thin & Lightweight
High Transparency
Flexible Design
Easy Installation
Customizable
Durable Performance
|
|
||
|---|---|---|
|
Module
|
LED Type
|
SMD1212
|
|
|
Pixel Configuration
|
1R1G1B
|
|
|
Module Resolution (w*h)
|
208 *104
|
|
|
Brightness
|
800cd/m2
|
|
|
Scan Mode
|
1/52
|
|
|
Refresh rate
|
3840Hz
|
|
|
Viewing Angle - Horizontal
|
150°
|
|
|
Viewing Angle - Vertical
|
140°
|
|
|
Grayscale
|
14 - 16 bits (RGB each)
|
|
|
Frame Frequency
|
60 fps
|
|
|
Maintenance
|
Front Service
|
|
|
Average Failure Free Time
|
100,000 hours
|
|
|
||
|---|---|---|
|
Mechanical
|
Pixel Patch
|
P 1.53
|
|
|
Module Size (w*h*d)
|
320 x160 x 15 mm
|
|
Power
|
Input Voltage
|
4.5±0.1V DC
|
|
|
Max Power Consumption
|
<23 W
|
|
|
Average Power Consumption (1/3 Max) (W)
|
~8 W
|
|
Environmental
|
Operating Temperature
|
-10ºC to +60ºC
|
|
|
Operating Humidity
|
10% to 65%
|
|
|
||
|---|---|---|
|
Module
|
LED Type
|
SMD1515
|
|
|
Pixel Configuration
|
1R1G1B
|
|
|
Module Resolution (w*h)
|
172 * 86
|
|
|
Brightness
|
800cd/m2
|
|
|
Scan Mode
|
1/43
|
|
|
Refresh rate
|
3840Hz
|
|
|
Viewing Angle - Horizontal
|
150°
|
|
|
Viewing Angle - Vertical
|
140°
|
|
|
Grayscale
|
14 - 16 bits (RGB each)
|
|
|
Frame Frequency
|
60 fps
|
|
|
Maintenance
|
Front Service
|
|
|
Average Failure Free Time
|
100,000 hours
|
|
|
||
|---|---|---|
|
Mechanical
|
Pixel Patch
|
P 1.86
|
|
|
Module Size (w*h*d)
|
320 x160 x 15 mm
|
|
Power
|
Input Voltage
|
4.5±0.1V DC
|
|
|
Max Power Consumption
|
<24 W
|
|
|
Average Power Consumption (1/3 Max) (W)
|
~8 W
|
|
Environmental
|
Operating Temperature
|
-10ºC to +60ºC
|
|
|
Operating Humidity
|
10% to 65%
|
|
|
||
|---|---|---|
|
Module
|
LED Type
|
SMD1515
|
|
|
Pixel Configuration
|
1R1G1B
|
|
|
Module Resolution (w*h)
|
172 * 86
|
|
|
Brightness
|
800cd/m2
|
|
|
Scan Mode
|
1/43
|
|
|
Refresh rate
|
3840Hz
|
|
|
Viewing Angle - Horizontal
|
150°
|
|
|
Viewing Angle - Vertical
|
140°
|
|
|
Grayscale
|
14 - 16 bits (RGB each)
|
|
|
Frame Frequency
|
60 fps
|
|
|
Maintenance
|
Front Service
|
|
|
Average Failure Free Time
|
100,000 hours
|
|
|
||
|---|---|---|
|
Mechanical
|
Pixel Patch
|
P 1.86
|
|
|
Module Size (w*h*d)
|
320 x160 x 15 mm
|
|
Power
|
Input Voltage
|
4.5±0.1V DC
|
|
|
Max Power Consumption
|
<24 W
|
|
|
Average Power Consumption (1/3 Max) (W)
|
~8 W
|
|
Environmental
|
Operating Temperature
|
-10ºC to +60ºC
|
|
|
Operating Humidity
|
10% to 65%
|
|
|
||
|---|---|---|
|
Module
|
LED Type
|
SMD1515
|
|
|
Pixel Configuration
|
1R1G1B
|
|
|
Module Resolution (w*h)
|
128 * 64
|
|
|
Brightness
|
800cd/m2
|
|
|
Scan Mode
|
1/32
|
|
|
Refresh rate
|
3840Hz
|
|
|
Viewing Angle - Horizontal
|
150°
|
|
|
Viewing Angle - Vertical
|
140°
|
|
|
Grayscale
|
14 - 16 bits (RGB each)
|
|
|
Frame Frequency
|
60 fps
|
|
|
Maintenance
|
Front Service
|
|
|
Average Failure Free Time
|
100,000 hours
|
|
|
||
|---|---|---|
|
Mechanical
|
Pixel Patch
|
P 2.5
|
|
|
Module Size (w*h*d)
|
320 x160 x 15 mm
|
|
Power
|
Input Voltage
|
4.5±0.1V DC
|
|
|
Max Power Consumption
|
<24 W
|
|
|
Average Power Consumption (1/3 Max) (W)
|
~8 W
|
|
Environmental
|
Operating Temperature
|
-10ºC to +60ºC
|
|
|
Operating Humidity
|
10% to 65%
|
